Curtain Wall Installation:
A Comprehensive Guide

Discover the epitome of architectural excellence with our revolutionary commercial curtain wall systems, engineered to enhance building efficiency, elevate aesthetics, and inspire awe-inspiring spaces.

What is considered a curtain wall?

A curtain wall, whether it's a stick curtain wall or a unitized curtain wall, is a non-structural exterior wall system frequently found in commercial and high-rise buildings. Typically constructed with aluminum frames and glass panels, this system seamlessly combines both aesthetics and functionality. The primary goal of curtain wall installation is to enclose the building, creating an attractive facade while allowing abundant natural light to penetrate the interior spaces.
curtain wall image 3
commercial curtain wall
What is the purpose of a curtain wall?
What is the purpose of a curtain wall?
Aluminum curtain walls, often used in commercial applications, serve several key functions. They provide protection from external elements like wind, rain, and temperature changes while maximizing natural light entry for a well-lit interior. Additionally, they enhance architectural aesthetics and offer customization options for creative designs. Curtain walls can also contribute to energy efficiency through features like thermal insulation and solar control systems, helping regulate indoor temperatures and reduce energy consumption.
What is the difference between a curtain wall and window wall?
What is the difference between a curtain wall and window wall?
The distinction between a curtain wall and a window wall lies in their structural characteristics. A curtain wall is a non-structural system that relies on the building's primary structural frame for support. It is designed to act as an outer layer, creating an enclosure while allowing for the entry of natural light. In contrast, a window wall is a structural system where the windows themselves provide support for the building, eliminating the need for additional framing elements. This design approach allows for larger expanses of glazing, providing unobstructed views and maximizing daylight penetration. While curtain walls offer flexibility in design and can accommodate various building shapes, window walls offer the advantage of simplicity in installation and potential cost savings by eliminating the need for separate structural support systems.
What are the two types of curtain walls?
What are the two types of curtain walls?
There are two main types of curtain walls: stick-built curtain walls and unitized curtain walls. Stick-built curtain walls are constructed on-site, where individual components, such as aluminum frames and glass panels, are assembled piece by piece. This method allows for greater flexibility in design, making it ideal for projects with unique requirements or irregular building shapes. On the other hand, unitized curtain walls are prefabricated in controlled factory conditions. They are transported to the construction site as pre-assembled units, including fully glazed panels, frames, and other necessary components. Unitized curtain walls offer the advantage of faster installation, as the prefabricated units can be quickly fitted together, reducing on-site labor and time. Both types of curtain walls have their respective benefits, and the choice between them depends on project specifications and construction requirements.
Are curtain walls expensive?
Are curtain walls expensive?
The cost of curtain walls can vary based on several factors. Factors such as the complexity of the design, the choice of materials, the size of the project, and the level of customization required all contribute to the overall cost. In general, curtain walls tend to be more expensive than traditional masonry walls or standard window systems. This is primarily due to the higher cost of materials, such as aluminum frames and high-quality glass panels, as well as the specialized installation techniques involved. However, it's important to note that while the initial investment may be higher, curtain walls can provide long-term benefits such as energy efficiency, reduced maintenance costs, and improved aesthetics, making them a worthwhile investment for many projects.
Can a curtain wall be structural?
Can a curtain wall be structural?
Curtain walls are not intended to serve as structural elements within a building. They are designed to provide an outer layer of the building envelope and do not bear the primary load of the structure. Instead, curtain walls rely on the structural support provided by the building's framework or internal structural elements, such as columns and beams. This means that the curtain wall system is installed independently of the building's structural system and does not contribute to its overall stability. By separating the structural and non-structural functions, curtain walls offer flexibility in architectural design, allowing for creative façade solutions without compromising the structural integrity of the building.
What are the disadvantages of curtain walls?
What are the disadvantages of curtain walls?
While curtain walls offer numerous advantages, there are some factors that can be considered as potential challenges or considerations. One potential consideration is the higher cost compared to other wall systems. The specialized materials, such as aluminum frames and high-quality glass panels, as well as the intricate installation process, contribute to the higher upfront investment. Additionally, proper installation and ongoing maintenance are crucial for the long-term performance of curtain walls. If not installed correctly, there may be issues with limited sound insulation and potential air leakage. Curtain walls can also be more vulnerable to damage from extreme weather conditions or impacts compared to more solid wall systems. Lastly, without proper design and insulation, there is a potential risk of thermal bridging, which can impact energy efficiency. It's important to address these factors during the design, installation, and maintenance processes to ensure optimal performance and longevity of the curtain wall system.
What is the difference between a façade and a curtain wall?
What is the difference between a façade and a curtain wall?
A façade represents the complete outer face of a building, encompassing all exterior elements like walls, windows, doors, and cladding. It refers to the overall appearance and visual character of the building's exterior. On the other hand, a curtain wall is a specific type of façade system. It refers to the non-structural panels or glazing elements that form part of the building's exterior. Unlike other components of the façade, curtain walls are typically supported by the building's structural framework, serving as a cladding system rather than bearing any structural load. In summary, a curtain wall is an integral part of the building's façade, contributing to its aesthetics and functionality, but it represents only a portion of the overall exterior appearance.
